Freightliner A/C Hose Assembly | A22-41331-016
Have a Question for Our Team?
Description
The A/C hose assembly known as A22-41331-016 has a length of 80 inches. It is equipped with #8 fittings, with one end having a 90 degree angle (adapter with a swivel nut for female connections) and the other end having a straight fitting (crimp-beaded female swivel nut). The construction incorporates synthetic rubber, steel fittings and tube material, along with an elastomer cover. The hose assembly has an inner diameter of 0.41 inches and an outer diameter of 0.73 inches, with a hose wall thickness of 0.16 inches. The first fitting is angled at 90 degrees and has a thread size of 1-14 UNS 2B, while the second fitting has a thread size of 3/4-16 UNF 2B and is also a #8 fitting. This assembly is designed to withstand bursts up to 1000 psi pressure.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- End 1 Fitting Type: Adapter with Female Swivel Nut
- End 2 Fitting Type: Crimp, Beaded Female Swivel Nut
- Hose Material: Synthetic Rubber
- Fitting Material: Steel
- Tube Material: Steel
- Cover Material: Elastomer
- Hose Inner Diameter: 0.41 in
- Hose Length: 77 in
- Hose Outer Diameter: 0.73 in
- Center To Center Length: 80 in
- Hose Wall Thickness: 0.16 in
- End 1 Fitting Angle: 90 deg
- Tube 2 Inner Diameter: 0.40 in
- Tube 2 Wall Thickness: 0.05 in
- Tube 2 Outer Diameter: 0.50 in
- End 1 Fitting Thread Size: 1-14 UNS 2B in
- End 2 Fitting Thread Size: 3/4-16 UNF 2B in
- Standard End 2 Fitting Size: #8
- Standard Hose Size: #8
- Burst Pressure: 1000 psi
| Manufacturer | Freightliner |
|---|---|
| Shipping Length (in) | 28.00 |
| Shipping Width (in) | 24.00 |
| Shipping Height (in) | 14.00 |
| Returnable | Yes |
| Weight (lb) | 1.56 |
| Core Exchange | No |
