Freightliner A/C Hose Assembly | A22-32945-094

Description

The A22-32945-094 is a hose assembly specifically designed for air conditioning systems. Its purpose is to connect the condenser to the receiver/dryer. It measures 94 inches in length. This hose assembly utilizes a #6 hose size and includes different fittings such as beaded female swivel nut fittings and 90-degree angles. The hose itself is made from nylon material while the fittings are constructed from steel. With a diameter of 0.32 inches, a diameter of 0.62 inches and a wall thickness of 0.15 inches, this hose guarantees durability and optimal performance for air conditioning systems.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Fitting Type: Beaded Female Swivel Nut
• End 1 Fitting Type: Beaded Female Swivel Nut
• End 2 Fitting Type: Beaded with Female Swivel Nut
• Hose Material: Nylon
• Fitting Material: Steel
• Tube Material: Steel
• Cover Material: Elastomer
• Hose Inner Diameter: 0.32 in
• Hose Length: 91.88 in
• Hose Outer Diameter: 0.62 in
• Tube Outer Diameter: 0.38 in
• Tube Wall Thickness: 0.04 in
• Center To Center Length: 94 in
• Hose Wall Thickness: 0.15 in
• Tube Inner Diameter: 0.30 in
• End 1 Fitting Angle: 90 deg
• End 2 Fitting Angle: 90 deg
• Fitting Angle: 90 deg
• Tube 1 Wall Thickness: 0.04 in
• Tube 2 Inner Diameter: 0.30 in
• Tube 1 Outer Diameter: 0.38 in
• Tube 2 Wall Thickness: 0.04 in
• Tube 2 Outer Diameter: 0.38 in
• Tube 1 Inner Diameter: 0.30 in
• Fitting Thread Size: 5/8-18 UNF 2B in
• End 1 Fitting Thread Size: 5/8-18 UNF 2B in
• End 2 Fitting Thread Size: 5/8-18 UNF 2B in
• Standard Fitting Size: #6
• Standard End 2 Fitting Size: #6
• Standard End 1 Fitting Size: #6
• Standard Hose Size: #6
• Burst Pressure: 1000 psi
