Freightliner 1/2 in. Female Threaded Right-HandSpherical Rod End | VCW 8
Have a Question for Our Team?
Description
The AUR VCW 8, manufactured by the Aurora Bearing Company, is a versatile spherical rod end designed with precise engineering and high-quality materials. With a bore diameter of 0.5000 inches (1/2 inch) and right-hand threads, it offers exceptional durability and reliability. Its alloy steel ball, PTFE composite race material and self-lubricating feature ensure smooth and long-lasting performance. With an overall height of 2.7810 inches and an ability to handle radial static loads of up to 7229 lbs., it's well-suited for various applications, including those in Freightliner vehicles, where it can be used for linkages and connections that demand flexibility and a wide range of motion.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Brand: Aurora Bearing Company
- Ball Material: Alloy Steel
- Ball Width: 0.6250 in
- Bore Diameter: 0.5000 in - 1/2 in
- Grade: Economy/General Purpose
- Harmonization Code: 8483.30.8055
- Head Diameter: 1.3120 in
- Head Width: 0.4530 in
- Housing Material: Low Carbon Steel
- Length to Ball Center: 2.1250 in
- Lubrication Type: Self-Lubricating
- Misalignment Angle: 16 º
- Overall Height: 2.7810 in
- Race Material: PTFE Composite
- Radial Static Load Capacity: 7229 lb.
- Rod End Type: Female Threaded
- Series: VCW
- Shank Thread Length: 1.0620 in
- Shank Thread Size: 1/2-20
- Thread Direction: Right Hand
- Thread Type: UNF-2B
- Product Type: Spherical Rod Ends
- Bearing Type: Spherical Rod Ends
- Bore Diameter: 0.5000 in
| Manufacturer | Freightliner |
|---|---|
| Shipping Length (in) | 6.00 |
| Shipping Width (in) | 4.00 |
| Shipping Height (in) | 4.00 |
| Returnable | Yes |
| Weight (lb) | 0.30 |
| Core Exchange | No |
