Donaldson Style 1 Round Muffler | M085171

Description

The DN M085171 is a Style 1 Round Muffler by Donaldson designed for various applications. It features an inlet diameter of 4.02 inches and an outlet diameter of 4.02 inches. The muffler's body has a maximum diameter of 8.46 inches and a body length of 34.12 inches, resulting in an overall length of 40.00 inches. This muffler is capable of handling different airflow rates, with a rated flow of 1798 cfm in the low range, 2546 cfm in the mid-range and 3118 cfm in the high range. It's equipped to manage back pressure, with 0.98 inches Hg (25 mm Hg) in the low range, 2.01 inches Hg (51 mm Hg) in the mid-range and 2.99 inches Hg (76 mm Hg) in the high range. The muffler provides noise reduction, attenuating sound by 8 dBA in the low range and 12 dBA in the high range, making it an effective component for noise control in various equipment and machinery.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Inlet Diameter: 4.02 in (102.12 mm)
• Outlet Diameter: 4.02 in (102.12 mm)
• Body Diameter Maximum: 8.46 in (214.88 mm)
• Body Length: 34.12 in (866.65 mm)
• Overall Length: 40.00 in (1016 mm)
• Rated Flow LR: 1798 cfm (50.9 m³/min)
• Rated Flow MR: 2546 cfm (72.1 m³/min)
• Rated Flow HR: 3118 cfm (88.3 m³/min)
• Back Pressure Low-Range: 0.98 in Hg (25 mm Hg)
• Back Pressure Mid-Range: 2.01 in Hg (51 mm Hg)
• Back Pressure High-Range: 2.99 in Hg (76 mm Hg)
• Attenuation LR: 8 dBA
• Attenuation HR: 12 dBA
• Style: Style 1
