Detroit Engine Oil Pressure Sensor | A0111539228

Description

The DDE A0111539228 Engine Oil Pressure Sensor plays a role in monitoring and transmitting information about the oil pressure in an engine. It comes with a durable glass fiber connector and has three pins. With a length of 55.97 mm and a thread size of M16 X 1.50 mm, this sensor can be easily installed in engine systems. It can operate perfectly within the temperature range of -40 to +130 degrees Celsius and can withstand pressure of up to 30 bar while maintaining a maximum pressure of 6 bar. The sensor operates on a voltage range of 4.75 to 5.25 VDC, ensuring oil pressure monitoring and safeguarding the engine's performance.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Connector Material: Glass Fiber
• Pin Count: 3
• Length: 55.97 mm
• Thread Size: M16 X 1.50 mm
• Working Temperature Range: -40 to +130 Deg. C
• Burst Pressure: 30 bar
• Maximum Pressure: 6 bar
• Voltage: 4.75 to 5.25 VDC
