ConMet Premium FL Front Hub | 10082215
Have a Question for Our Team?
Description
The CM 10082215 is an assembly preset designed for FL (front engine front-wheel drive) and FR (front engine rear-wheel drive) configurations featuring an HP10 hub type. The assembly includes 10 studs, ensuring secure wheel attachment. It is equipped with the inboard bearing set 445 and the outboard bearing set 446, providing reliable wheel support and rotation. With a hub rating of 11,500 lbs., this assembly is capable of handling heavy loads and offers enhanced durability.,In terms of dimensions, the bolt circle diameter is 285.75 mm, providing the measurement for the circle formed by the bolt holes on the hub. The wheel stud bolt circle diameter is 11.25 in., indicating the spacing of the wheel studs on the assembly. The hub offset is 4.29 in., referring to the distance between the wheel mounting surface and the centerline of the hub. The wheel stud thread size is M22 X 1.5 mm, ensuring compatibility with the corresponding wheel studs. The wheel stud standout is 3.3 in., indicating the distance between the wheel mounting surface and the outer end of the stud. Constructed from iron, this assembly provides robustness and strength. The brake type is drum, indicating the type of braking mechanism used in the assembly. The axle type is FL (front engine front-wheel drive) and the axle position is front, specifying the intended placement of the assembly on the vehicle. Please ensure compatibility with your specific vehicle make and model and follow the proper installation procedures and maintenance guidelines recommended by the manufacturer or a qualified professional.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Stud Quantity: 10
- Hub Type: HP10
- Inboard Bearing Set: 445
- Outboard Bearing Set: 446
- Hub Rating: 11500 lbs.
- Bolt Circle Diameter: 285.75 mm
- Wheel Stud Bolt Circle Diameter: 11.25 in
- Hub Offset: 4.29 in
- Wheel Stud Thread Size: M22 X 1.5 mm
- Wheel Stud Standout: 3.3 in
- Material: Iron
- Brake Type: Drum
- Axle Type: FL (Front Left)
- Axle Position: Front
| CONMET | 10083793 | |
|---|---|---|
| CONSOLIDATED METCO INC. | 10082215 | |
| SUPERCEDE | 10014453 |
| Manufacturer | ConMet |
|---|---|
| Shipping Length (in) | 28.00 |
| Shipping Width (in) | 24.00 |
| Shipping Height (in) | 14.00 |
| Returnable | Yes |
| Weight (lb) | 75.00 |
| Core Exchange | No |
