ConMet Premium Drive Hub | 10082219

Description

The CM 10082219 is a robust Rear Drive Wheel Hub Assembly specifically designed as a Preset Premium HP10 hub with a high hub rating of 13,000 lbs. for heavy-duty applications. Crafted from durable iron, it features drum brakes and is intended for use on the drive axle (position R) of vehicles. Key dimensions include an 11.25 inch wheel stud bolt circle diameter, 2.33 inch ABS offset and a 1.31 inch hub offset. This assembly includes 10 mounting studs, M22 X 1.5 mm wheel stud threads and 5/8-11 UNC in axle stud threads, ensuring dependable performance and safety for rear drive wheels.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Hub Rating: 13000 lbs.
• Material: Iron
• Brake Type: Drum
• Axle Type: R (Rear)
• Axle Position: Drive
• Wheel Stud Bolt Circle Diameter: 11.25 in
• ABS Offset: 2.33 in
• Hub Offset: 1.31 in
• Drum Pilot Diameter: 8.78 in
• Axle Stud Diameter: 0.63 in
• Wheel Stud Thread Size: M22 X 1.5 mm
• Wheel Stud Standout: 3.97 in
• Axle Stud Thread Size: 5/8-11 UNC
• Mounting Stud Quantity: 10
• Thread Direction: RH (Right-Hand Thread)
• Hub Type: HP10
• Inboard Bearing Set: 429
• Outboard Bearing Set: 430
