ConMet Premium Drive Hub | 10082218

Description

The CM 10082218, known as the ConMet Premium Drive Hub, is specifically designed for fitting into the drive axle of commercial vehicles. This hub is built to last, with its durable construction made from iron and ductile iron casting material. It is primarily intended for vehicles equipped with drum brake systems and is suitable for use on the rear axle (R). With a high hub rating of 13,000 lbs., it is well suited for heavy-duty applications. The hub comes equipped with 10 wheel studs that have a thread size of M22 X 1.5 mm and a stud standout measurement of 3.06 inches. Additionally, it features an ABS (Anti-lock Braking System) and has a brake pilot diameter measuring 8.78 inches. The specific type of this hub is HP10, which incorporates inboard bearing set 429 and outboard bearing set 430. It is designed with right-hand thread direction in mind and should be used exclusively on the drive axle. Furthermore, the specifications of this hub include ABS offset, hub offset and axle stud thread size, alongside other notable features.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Material: Iron
• Brake Type: Drum
• Axle Type: R (Rear)
• Casting Material: Ductile Iron
• Axle Position: Drive
• Hub Rating: 13000 lbs.
• Brake Pilot Diameter: 8.78 in
• Wheel Stud Bolt Circle Diameter: 11.25 in
• Stud Standout: 3.06 in
• ABS Offset: 2.33 in
• Hub Offset: 1.31 in
• Wheel Stud Thread Size: M22 X 1.5 mm
• Wheel Stud Standout: 3.06 in
• Axle Stud Thread Size: 5/8-11 UNC in
• Mounting Location: Drive Axle
• ABS Included: Yes
• Stud Quantity: 10
• Thread Direction: RH (Right-Hand Thread)
• Hub Type: HP10
• Inboard Bearing Set: 429
• Outboard Bearing Set: 430
