ConMet Drive Preset Hub Assembly | 10082216
Have a Question for Our Team?
Description
The CM 10082216 represents a ConMet Drive Preset Hub Assembly made of aluminum. Specifically designed for drum brakes, this hub assembly is meant to be used on the drive axle position. The hub has a capacity rating of 11,500 lbs. and a thickness of 1.34 inches. Its pilot diameter measures around 8.78 inches while the stud diameter is 0.63 inches. The wheel stud bolt circle diameter spans about 11.25 inches with an offset of 1.31 inches from the centerline of the hub assembly itself. The thread size for the wheel studs is M22 X 1.5 mm, with a projection length measuring 2.94 inches from the surface of the hub assembly to where it extends beyond it in relation to the wheel stud threads themselves.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Material: Aluminum
- Brake Type: Drum
- Axle Type: R
- Axle Position: Drive
- Hub Rating: 11500 lbs.
- Thickness: 1.34 in
- Pilot Diameter: 8.78 in
- Stud Diameter: 0.63 in
- Wheel Stud Bolt Circle Diameter: 11.25 in
- Hub Offset: 1.31 in
- Wheel Stud Thread Size: M22 X 1.5 mm
- Wheel Stud Standout: 2.94 in
- Axle Stud Thread Size: 5/8-11 UNC
- Stud Quantity: 10
- Thread Direction: RH (Right-Hand Thread)
- Hub Type: HP10
- Inboard Bearing Set: 429
- Outboard Bearing Set: 430
| CONMET | 10001342, 10001571, 10004029, 10005581, 10020297 | |
|---|---|---|
| CONSOLIDATED METCO INC. | 10082216, 10083794 | |
| OTHER | 10023537 |
| Shipping Weight (lb) | 36.00 |
|---|---|
| Manufacturer | ConMet |
| Shipping Length (in) | 16.00 |
| Shipping Width (in) | 16.00 |
| Shipping Height (in) | 17.00 |
| Returnable | Yes |
| Core Exchange | No |
-
