ConMet 16.5 in. x 8.62 in. Rear Brake Drum | 10037825
Have a Question for Our Team?
Description
The CM 10037825 is a rear brake drum that is designed for specific applications. It has a width of 8.62 inches and a thickness of 0.50 inches. The bolt circle diameter measures 11.25 inches and the drum is equipped with 10 bolt holes, each having a diameter of 1.10 inches. To match the width of the drum at 8.62 inches, the brake shoe width has been set accordingly. The overall depth of the drum is measured at 11.37 inches, ensuring proper contact with the brake pads, which have a pad contact surface width of 9.04 inches. Both the pilot diameter and brake pilot diameter are specified at 8.78 inches for this rear brake drum model. The brake surface itself has a diameter of 16.50 inches, providing ample surface area for effective braking performance. The mounting flange thickness measures 0.50 inch. In terms of aesthetics, this CM10037825 rear brake drum comes in black color with a painted finish. It is specifically designed to be used in the rear axle position. Please ensure proper fitment and adhere to the manufacturer's guidelines for installation and usage when utilizing this CM10037825 rear brake drum.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Width: 8.62 in
- Thickness: 0.50 in
- Bolt Circle Diameter: 11.25 in
- Hole Diameter: 1.10 in
- Brake Shoe Width: 8.62 in
- Overall Depth: 11.37 in
- Pad Contact Surface Width: 9.04 in
- Pilot Diameter: 8.78 in
- Bolt Hole Diameter: 1.10 in
- Brake Pilot Diameter: 8.78 in
- Brake Surface Diameter: 16.50 in
- Mounting Flange Thickness: 0.50 in
- Bolt Hole Quantity: 10
- Color: Black
- Finish: Painted
- Axle Position: Rear
- Weight: 115 lbs.
| BLUE BIRD | BP0102779-66814B | |
|---|---|---|
| CONSOLIDATED METCO INC | 10012097, 107638 | |
| DURABRAKE CO. | 16854X | |
| FLEETPRIDE | OTR1615B, OTR16585B | |
| FREIGHTLINER/DAIMLER TRK | CM10012097, CM10037825, GUN3807A, GUN3807AX CM107638, TBB184962, CM10033314 | |
| GUNITE BRAKE DRUMS | 3807A, 3807AX, 3807X | |
| I H C TRUCK | CNM10012097, FLT4407B, ZBR3807A, 4115969C1 CNM107638, 07262C1, 6107262C1, ZBR3780A, 2605078C1 | |
| KENWORTH | CM10012097, 3807AX | |
| KIC | 54229-01 | |
| M&K TRAILER | WEB66814 | |
| MACK | 20458893, 3398-3807X, 33983807X 17QF491, 17QJ4137, 25036970 | |
| MERITOR AUTOMOT./ROCKWELL | 85123570002 | |
| MOTOR WHEEL CORP | 90486B | |
| OTHER | ABP N42A1658625B, ACC3807X, CM10012097, CM10037825, CNM10012097, GUN3807AX, GUN3807AXWB, ZBR3807A, ZBR3807X, 33983807AX, 33983807X CNM107638, 07262C1, 6107262C1, ZBR3780A | |
| THOMAS BUILT BUSES | 61120778 | |
| VOLVO-WHITE VENDOR DIRECT | GUN3807A, GUN3807AX, GUN3807X, WEB66814B | |
| VOLVO/WHITE | GUN3807AX, 20458893 | |
| SUPERSEDED | CM107638, TBB184962, CM10033314, CNM107638, 07262C1, 6107262C1, ZBR3780A, 2605078C1, 17QF491, 17QJ4137, 25036970, CNM107638, 07262C1, 6107262C1, ZBR3780A |
| Manufacturer | ConMet |
|---|---|
| Shipping Length (in) | 28.00 |
| Shipping Width (in) | 24.00 |
| Shipping Height (in) | 14.00 |
| Returnable | Yes |
| Weight (lb) | 114.60 |
| Core Exchange | No |
