Caterpillar Seal O-ring (SAE 11/16-16) | 2287089

Description

The 2287089 SEAL-O-ring ORFS (SAE 11/16-16) is designed for use in O-ring face seal (ORFS) connections with a fitting size of 11/16 - 16. It features a primary sealing material made of FKM rubber, known for its resilience to air, fuel (including bio-diesel), lubricants and oils. With a hardness rating of 90 Shore A, this seal ensures durability and longevity. The seal is characterized by a cross-section diameter of 0.07-inches, an inside diameter of 0.365 inches and an outside diameter of 0.505-inches, all aligned with the SAE AS568 Dash Size of -12. Its light blue color allows for easy identification and the PTFE coating adds protection during installation while facilitating ease of assembly. It's important to note that while FKM rubber is versatile, it's not recommended for applications requiring resistance to water or coolant. This seal is particularly suitable for applications where temperatures range from -40° C to 150° C.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Fitting Size (in): 11/16 – 16
• Primary Sealing Material: Rubber
• O-ring Type: O-ring Face Seal (ORFS)
• Cross-Section Diameter (in): 0.07
• Inside Diameter (in): 0.365
• Outside Diameter (in): 0.505
• Hardness (Shore A): 90
• SAE AS568 Dash Size: -12
• Color: Light Blue
• Material: FKM
• Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
• Coating: PTFE coating protects the O-ring from installation damage and provides ease of assembly.
