Caterpillar Seal O-ring | 3D2824

Description

The 3D2824 seal is an O-ring made from Nitrile rubber that is specifically designed to be used in a variety of applications. It can function effectively within a temperature range of -40° F to 212° F. It has a Dash Size measurement of 912. This particular O-ring is compatible with lubricants that are resistant to abrasion as well as hydrocarbon fuels and other substances. However, it is important to note that it may not be suitable for use with bio-diesel or if you require resistance to coolants. The dimensions of this O-ring include a section diameter of 0.116 inches, an inside diameter of 0.924 inches and an outside diameter of 1.156 inches.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Not Compatible With: Automotive and aircraft brake fluids; High levels of ozone; Ketones; Phosphate ester fluids; Strong acids; UV light
• O-ring Type: Straight Thread O-ring (STOR)
• Compatible With: Abrasion resistant; Alpha-Olefin base synthetic lubricants; Ethylene Glycol; Hydrocarbon fuels; Petroleum base lubricants; Silicone oils and greases; Water, water base engine coolants; ORFS, STORS seals
• Fitting Size (in): 1-1/16 – 12
• Ambient temperature fuel handling; High and low-pressure LPG service; Hydraulic fluids (to 10,335 kPa/1,500 psi); Power steering seals; Radiator thermostat seals
• Primary Sealing Material: Rubber
• Dash Size (in): 912
• Temperature (° F): -40° - 212°
• Cross-Section Diameter (in): 0.116
• Inside Diameter (in): 0.924
• Outside Diameter (in): 1.156
• Hardness (Shore A): 90
• SAE AS568 Dash Size: -912
• Color: Black
• Material: Nitrile (NBR)
• Material Description: Nitrile (NBR) rubber is capable of service temperatures of -40 to 100° C and is resistant to fuel, oils, gasoline, ultra-low sulfur diesel fuel and lubricants. Nitrile rubber is not recommended for applications that require resistance to bio-diesel or coolant.
