Bendix SC-3 Single Check Valve, 90 Degree, 1/2" NPT Ports, Female Inlet, Male Outlet | K112234

Description

The Bendix SC-3 Single Check Valve, model number BW K112234, plays a role in air brake systems by controlling and regulating air pressure. Specifically designed for this purpose, this valve is equipped with 90-degree ports and 1/2 NPT threads to ensure a connection. To guarantee a leak-free seal during installation, it comes pre-applied with thread sealant. This valve performs reliably across a range of temperatures (-40.00 to +250.00 Deg. F), making it suitable for many conditions. It has dimensions of 51.56 mm in length, 38.10 mm in width and 47.24 mm in height. The inlet and outlet ports are threaded with 1/2-14 NPTF threads.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Length: 51.56 mm
• Width: 38.10 mm
• Height: 47.24 mm
• Thread Size: 1/2 NPT in
• Inlet Port Thread Size: 1/2-14 NPTF in
• Outlet Port Thread Size: 1/2-14 NPT in
• Thread Sealant: Pre-Applied
• Body Type: 90 degree
• Valve Type: Single Check Valve
• Working Temperature Range: -40.00 to +250.00 Deg. F
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 250 Deg. F
