Bendix R-12 Relay Valve | 102626N

Description

The Bendix R-12 Relay Valve with model number BW 102626N is a part used in air brake systems to regulate and control air pressure. This relay valve has been designed with four delivery ports and one supply port, along with a dust shield-equipped exhaust port, to ensure performance in rough conditions. It can operate efficiently within a temperature range of -40° F to 200° F, making it suitable for various situations. The valve has dimensions measuring 101 mm in length, 101 mm in width and 98 mm in height, with a mounting dimension of 0.96 X 0.40 inches. The control port thread size is 1/4-18 NPT while the supply port (port 1) and delivery ports (ports 1 to 4) have a thread size of 1/2-14 NPT.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Crack Pressure: 4 psi
• Delivery Port Quantity: 4
• Number Of Supply Port: 1
• Exhaust Port Type: Dust Shield
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
• Length: 101 mm
• Width: 101 mm
• Height: 98 mm
• Mounting Dimension: 0.96 X 0.40 in
• Control Port Thread Size: 1/4-18 NPT in
• Supply Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 2 Thread Size: 1/2-14 NPT in
• Delivery Port 3 Thread Size: 1/2-14 NPT in
• Delivery Port 4 Thread Size: 1/2-14 NPT in
