Bendix R-12 Relay Valve | 065125

Description

The Bendix R 12 Relay Valve, also known as the BW 065125, is a component of the air brake system found in vehicles. Its main purpose is to regulate and control the airflow that goes into the brake chambers, ensuring effective braking performance. This valve is specifically designed to operate in a range of temperatures from -40° F to 200° F, making it suitable for environmental conditions. With two delivery ports and two supply ports, it enables the distribution of air throughout the brake system. Its crack pressure of 5.50 psi ensures that the brakes engage when necessary, greatly contributing to vehicle safety. Thanks to its control and sturdy construction, the Bendix R 12 Relay Valve plays a role in maintaining optimal functionality and safety for commercial vehicles equipped with air brake systems.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Crack Pressure: 5.50 psi
• Delivery Port Quantity: 2
• Number Of Supply Port: 2
• Exhaust Port Type: Dust Shield
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
• Length: 102 mm
• Width: 102 mm
• Height: 94 mm
• Mounting Dimension: 0.96 X 0.40 in
• Delivery Port Thread Size: 1/2 NPT in
• Control Port Thread Size: 1/4-18 NPT in
• Supply Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 2 Thread Size: 1/2-14 NPT in
• Supply Port 2 Thread Size: 1/2-14 NPT in
