Bendix Quick Release Valve | 802744

Description

The Bendix Quick Release Valve, model BW 802744, is a part of an air brake system that ensures control over the release of air pressure. This valve is designed with an exhaust port and has the capability to hold pressure consistently. It performs optimally in a range of temperatures from as low as -50° F to as high as 200° F. The valve has a pressure rating of 1 psi, guaranteeing control. In terms of dimensions, it measures 76.71 mm in length, 101.60 mm in width and 2.25 mm in height. The mounting dimension is 0.34 X 0.75 inches. It requires a mounting length of 1.50 inches. To facilitate integration into brake systems, the supply port, inlet port, outlet port and delivery ports all have thread sizes of either 3/8-18 NPT or PT.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Exhaust Port Type: Open
• Zero Hysteresis: No
• Sustained Hold: Yes
• Minimum Operating Temperature: -50 Deg. F
• Maximum Operating Temperature: 200 Deg. F
• Differential Pressure: 1 psi
• Length: 76.71 mm
• Width: 101.60 mm
• Height: 2.25 mm
• Mounting Dimension: 0.34 X 0.75 in
• Mounting Length: 1.50 in
• Supply Port Thread Size: 3/8-18 NPT in
• Inlet Thread Size: 3/8-NPT in
• Outlet Thread Size: 3/8-PT in
• Delivery Port 1 Thread Size: 3/8-18 NPT in
• Delivery Port 2 Thread Size: 3/8-18 NPT in
