Bendix PP-DC Dash Valve | 800147
Have a Question for Our Team?
Description
The Bendix PP-DC Dash Valve identified by part number BW 800147 is a vital component within air brake systems. This valve is equipped with buttons to provide precise control over the brake system and is designed to operate effectively within a wide range of tractor trip pressures spanning from 30 to 40 psi. With a weight of approximately 0.53 kg and the ability to withstand temperatures ranging from -40° F to 200° F, this valve is built to deliver consistent performance in various environmental conditions. Its compact dimensions measuring 131.32 mm in length, 136.14 mm in width and 91.95 mm in height, make it suitable for installation in air brake systems. Additionally, its multiple port thread sizes ensure compatibility and ease of connection in the braking system. Overall, the BW 800147 dash valve is a dependable and precise control solution for air brake applications.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Buttons Included: Yes
- Tractor Trip Pressure: 30 to 40 psi
- Weight: 0.53 kg
- Minimum Operating Temperature: -40 Deg. F
- Maximum Operating Temperature: 200 Deg. F
- Length: 131.32 mm
- Width: 136.14 mm
- Height: 91.95 mm
- Exhaust Port Thread Size: 3/8 PTC in
- Fitting Size: 1/4 in
- Mounting Thread Size: M5 x 0.8-6H mm
- Delivery 21 Port Thread Size: 3/8 PTC in
- Supply 11 Port Thread Size: 3/8 PTC in
- Supply 12 Port Thread Size: 3/8 PTC in
| BENDIX | 800147 | |
|---|---|---|
| OTHER | 5002850, 5002851, 745-800147, 170.800147, ZAC800147, 800147BXW, BAN800147, BEN800147, BW800147, BX800147, S-28085, 170800147, 745800147, S28085 |
| Manufacturer | Bendix |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Weight (lb) | 1.17 |
| Core Exchange | No |
