Bendix MV-3 Valve Dash Control Module | 800529

Description

The Bendix MV-3 Valve Dash Control Module, also known as the BW 800529, is an efficient control module that is specifically designed to effectively manage and regulate air delivery and pressure in commercial vehicles. This control module provides control with its two delivery ports and user-friendly buttons for easy operation. It has dimensions measuring at 128.52 mm in length, 209.30 mm in width and 78.99 mm in height, making it a powerful yet space-saving component. This control module plays a role in ensuring the efficient operation of commercial vehicles by effectively managing air pressure and delivery under various conditions.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Style: MV-3
• Delivery Port Quantity: 2
• Number Of Delivery Port: 2
• Buttons Included: Yes
• Length: 128.52 mm
• Width: 209.30 mm
• Height: 78.99 mm
• Mounting Dimension: 0.20 in
• Exhaust Port Thread Size: 1/4-18 NPT in
• Delivery 21 Port Thread Size: 1/4-18 NPT in
• Delivery 22 Port Thread Size: 1/4-18 NPT in
• Supply 11 Port Thread Size: 1/4-18 NPT in
• Supply 12 Port Thread Size: 1/4-18 NPT in
• Tractor Trip Pressure: 20 to 40 psi
• Trailer Trip Pressure: 25 to 45 psi
• Trailer Override Pressure: 20 to 30 psi
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
