Bendix MV-3 Dash Valve | 802804

Description

The Bendix MV 3 Dash Valve model BW 802804 is a versatile control component designed to enhance the performance of your vehicle's air brake system. It is equipped with user buttons that make it easy to operate and integrate into your vehicle. The precise measurements of the MV 3 dash valve are 151.38 mm in length, 182.12 mm in width and 73.66 mm in height, ensuring air control within your braking system. It offers port sizes and thread sizes to seamlessly fit into your air brake setup. With a temperature tolerance ranging from -40° F to 200° F, this dash valve guarantees performance under diverse operating conditions.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Buttons Included: Yes
• Length: 151.38 mm
• Width: 182.12 mm
• Outlet Diameter: 0.37 in
• Inlet Diameter: 0.37 in
• Height: 73.66 mm
• Mounting Dimension: 0.23 in
• Exhaust Port Diameter: 0.37 in
• Supply Port Thread Size: 3/8 PTC in
• Delivery Port Thread Size: 3/8 PTC in
• Exhaust Port Thread Size: 3/8 PTC in
• Delivery 21 Port Thread Size: 3/8 PTC in
• Delivery 22 Port Thread Size: 3/8 PTC in
• Supply 11 Port Thread Size: 3/8 PTC in
• Supply 12 Port Thread Size: 3/8 PTC in
• Tractor Trip Pressure: 30 psi
• Trailer Trip Pressure: 35 psi
• Trailer Override Pressure: 25 psi
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
