Bendix MV-3 Dash Valve | 800573

Description

The Bendix MV 3 Dash Valve, also known as the BW 800573, is an efficient and compact control valve designed for truck /trailer systems. It comes with user buttons for operation and control. Its dimensions, which are 128.52 mm long, 136.22 mm wide and 91.95 mm high, make it suitable for installation in tight spaces. With inlet and delivery port thread sizes of around 0.25 inches and an operating temperature range spanning from -40 degrees F to 200 degrees F, this valve offers versatility and reliability in managing air pressure across many applications. The Bendix MV 3 Dash Valve plays a role in controlling air pressure, an essential component needed for effective functioning of pneumatic systems under different temperatures and operating conditions.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Buttons Included: Yes
• Length: 128.52 mm
• Width: 136.22 mm
• Height: 91.95 mm
• Inlet Port Thread Size: 0.25 in
• Delivery Port Thread Size: 0.25 in
• Exhaust Port Thread Size: 1/4-18 NPT in
• Mounting Thread Size: 1/4-20 UNC 2B in
• Delivery 21 Port Thread Size: 1/4-18 NPT in
• Delivery 22 Port Thread Size: 1/4-18 NPT in
• Supply 11 Port Thread Size: 1/4-18 NPT in
• Supply 12 Port Thread Size: 1/4-18 NPT in
• Tractor Trip Pressure: 30 psi
• Trailer Trip Pressure: 35 psi
• Trailer Override Pressure: 25 psi
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
