Bendix K025306 D-2A Governor, 105-130 PSI Pressure Range | K025306
Have a Question for Our Team?
Description
The Bendix K025306 D-2A Governor, also known as the BW K025306, plays a role in air brake systems by regulating and maintaining the air pressure within a specific range. It is specifically designed to function in a range of temperatures from -40° F to 250° F, ensuring optimal performance in different environmental conditions. This governor has a pressure range of 105-130 psi and is equipped with cut-in and cut-out pressure settings at 105 psi and 125 psi. These specifications make it well suited for controlling the air pressure in the vehicle's braking system. Moreover, it offers compatibility with port thread sizes commonly found in air brake system connections. The Bendix K025306 D-2A Governor plays a role in ensuring both safety and effectiveness in a vehicle's braking mechanism.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Minimum Operating Temperature: -40 Deg. F
- Maximum Operating Temperature: 250 Deg. F
- Adjustable: No
- Weather Resistant: No
- Length: 65.53 mm
- Width: 66.29 mm
- Height: 117.35 mm
- Mounting Dimension: 0.34 in
- Exhaust Port Thread Size: 1/8-27 NPT in
- Unloader Port Thread Size: 1/8-27 NPT in
- Reservoir Port 1 Thread Size: 1/8-27 NPT in
- Reservoir Port 3 Thread Size: 1/8-27 NPT in
- Reservoir Port 2 Thread Size: 1/8-27 NPT in
- Operating Pressure: 130 bar
- Pressure Settings Cut In: 105 psi
- Pressure Settings Cut Out: 125 psi
| OTHER | 060-K025306, 5010670, 745-5010670, BAN5010670, BW5010670, BWK025306, BX5010670, BXK025306, K045375, ZAC5010670 |
|---|
| Manufacturer | Bendix |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Weight (lb) | 1.27 |
| Core Exchange | No |
