Bendix E-6 Foot Brake Valve | 802911
Have a Question for Our Team?
Description
The BW 802911 Bendix E-6 Foot Brake Valve is a dependable component specifically designed for dual brake systems in different types of vehicles. This foot brake valve is constructed to meet the safety and performance requirements set by FMVSS 121 regulations. It includes a rubber spring that enables efficient control over braking. With dimensions measuring 88.13 mm in length, 88.13 mm in width and 141.73 mm in height, this valve offers a highly effective solution for braking requirements. Additionally, it boasts temperature resistance capabilities, withstanding temperatures ranging from -40° F to 221° F, making it suitable for a wide range of operating conditions.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Spring Material: Rubber
- Valve Type: Dual Brake Valve
- Exhaust Port Type: Dust Shield
- Water Resistance: No
- Regulatory Compliance: FMVSS 121
- Retarder Included: No
- Pedal Included: No
- Mounting Plate Included: No
- Port Configuration: Axial/Perpendicular
- Differential Pressure: 3 psi
- Length: 88.13 mm
- Width: 88.13 mm
- Height: 141.73 mm
- Valve Body Mounting Thread Size: 5/16-18 UNC-3B in
- Delivery 21 Port 1 Thread Size: 3/8-18 NPT in
- Delivery 21 Port 2 Thread Size: 3/8-18 NPT in
- Delivery 22 Port 2 Thread Size: 3/8-18 NPT in
- Delivery 22 Port 1 Thread Size: 3/8-18 NPT in
- Supply 11 Port 2 Thread Size: 3/8-18 NPT in
- Supply 12 Port 1 Thread Size: 3/8-18 NPT in
- Supply 12 Port 2 Thread Size: 3/8-18 NPT in
- Supply 11 Port 1 Thread Size: 3/8-18 NPT in
- Minimum Operating Temperature: -40 Deg. F
- Maximum Operating Temperature: 221 Deg. F
| BENDIX | 802911, 802911BXW | |
|---|---|---|
| OTHER | 20990660, 745-802911, 20990654, 745802911 |
| Manufacturer | Bendix |
|---|---|
| Shipping Length (in) | 8.00 |
| Shipping Width (in) | 8.00 |
| Shipping Height (in) | 6.00 |
| Returnable | Yes |
| Weight (lb) | 2.32 |
| Core Exchange | No |
