In Stock!

Bendix E-6 Brake Valve | 286171N

SKU
BW 286171N
MPN
286171N
$139.51

Free Shipping on qualifying orders of $150 or more.Details

Have a Question for Our Team?

Our Customer Service team is ready to help. Call 1.877.DL.ORDER or Monday - Friday 8 AM - 4:30 PM ET

Description

The BW 286171N brake valve known as the Bendix E-6 Brake Valve has been specifically designed to regulate and control the air pressure within brake systems. Its primary purpose is to ensure efficient braking. Weighing in at 0.96 kg, this valve is equipped with rubber springs and adheres to the standards set by FMVSS 121. Its crucial role lies in maintaining an air pressure that allows for brake operation. In a range of applications, the BW 286171N Bendix E-6 Brake Valve serves as a component in guaranteeing properly regulated air pressure within brake systems, ultimately contributing to overall safety and reliable braking performance.

WarningWARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

  • Spring Material: Rubber
  • Exhaust Port Type: Dust Shield
  • Water Resistance: No
  • Regulatory Compliance: FMVSS 121
  • Retarder Included: No
  • Pedal Included: No
  • Mounting Plate Included: No
  • Port Configuration: Axial/Perpendicular
  • Differential Pressure: 3 psi
  • Length: 88.13 mm
  • Width: 88.13 mm
  • Height: 141.73 mm
  • Valve Body Mounting Thread Size: 5/16-18 UNC 3B in
  • Delivery 21 Port 1 Thread Size: 3/8-18 NPT in
  • Delivery 21 Port 2 Thread Size: 3/8-18 NPT in
  • Delivery 22 Port 2 Thread Size: 3/8-18 NPT in
  • Delivery 22 Port 1 Thread Size: 3/8-18 NPT in
  • Supply 11 Port 2 Thread Size: 3/8-18 NPT in
  • Supply 12 Port 1 Thread Size: 3/8-18 NPT in
  • Supply 12 Port 2 Thread Size: 3/8-18 NPT in
  • Supply 11 Port 1 Thread Size: 3/8-18 NPT in
  • Minimum Operating Temperature: -40 Deg. F
  • Maximum Operating Temperature: 200 Deg. F
Cross Reference
AUTOMANN170286171, 170.286171
BENDIX286171, 286171N, BX286171N, 286171RX, 0R286171, 229501N, 275242N, 277863N, 278998N, OR286171, OR286171X, 286173N
DAYTON PARTSAV286171N
FLEETRITEFLTBV6171
GATES34039
HALDEXKN22150
HENDRICKSONS4771
HOLLAND EQUIPMENT, LTD.90001264
MERITORR955286171N
OTROTR286171
PAILFV-3630
PRIMA BRAKE COMPONENTSAV286171
S & S TRUCK PARTSS-4771
TMC401133
OTHER745286171, OR286171BXR, BW286171N, 745286171N, BAN286171N, BEN286171, 034039, BW286171, BW286171N, LFV3630, P0286171
More Information
Manufacturer Bendix
Shipping Length (in) 8.00
Shipping Width (in) 8.00
Shipping Height (in) 6.00
Returnable Yes
Weight (lb) 2.28
Core Exchange No
