Bendix Disc Service Brake Chamber | K028022

Description

The BW K028022 Bendix Disc Service Brake Chamber is designed to provide reliable and efficient braking performance in heavy-duty vehicles equipped with disc brake systems. This high-quality brake chamber is responsible for converting air pressure into mechanical force to operate the brake mechanism, ensuring responsive and consistent braking. Built for durability, the Bendix Disc Service Brake Chamber is engineered to withstand harsh conditions and deliver long-lasting performance. Ideal for commercial vehicles, it helps maintain the effectiveness of the braking system, improving safety and vehicle control.

Features

• Chamber Type:T18
• Stroke Length:2.50 in
• Push Rod Length:0.59 in
• Stud Thread Size:M16 X 1.50 mm
• Mounting Stud Center to Center Length:4.75 in
• Mounting Stud Length:1.7 in
• Service Port 11 Thread Size:3/8-18 NPTF in
• Minimum Operating Temperature:-40 Deg.F
• Maximum Operating Temperature:176 Deg.F
