Bendix Desiccant Cartridge for AD-IS and AD-SP Air Dryers | 5008414
Have a Question for Our Team?
Description
The Bendix Desiccant Cartridge model number BW 5008414 is a part used in AD-IS and AD-SP air dryers. Its primary function is to remove moisture from the compressed air found in a truck's braking system. This particular cartridge is designed for high-pressure applications of handling up to 203 psi of pressure. It has a user spin-on style for replacement and maintenance. Operating efficiently in temperatures ranging from -40° F to 160° F, this cartridge ensures that the air within the brake system remains dry and moisture free, contributing to dependable braking performance. With dimensions measuring 164.85 mm lengthwise, 140.21 mm widthwise and 6.50 mm heightwise, it has a diameter of 5.52 inches and features an M39X1.5 mm thread size as well. Due to its role in preserving the integrity of the air brake system under environmental conditions, this component is crucial for optimal performance.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Cartridge Type: Standard
- Maximum Operating Pressure: 203 psi
- Cartridge Style: Spin-On
- Minimum Operating Temperature: -40 Deg. F
- Maximum Inlet Temperature: 160 Deg. F
- Length: 164.85 mm
- Width: 140.21 mm
- Height: 6.50 mm
- Diameter: 5.52 in
- Thread Size: M39X1.5 mm
- Cartridge Thread Size: M39 X 1.5 mm
| AUTOMANN | 170.109994 | |
|---|---|---|
| BENDIX | 109994, 5008414, 109994K | |
| EUCLID | E109994P | |
| IHC | 1699595C1 | |
| MACK | 745109994 | |
| MERITOR | R109994, R950011, S-A323 | |
| PETERBILT | ADC1000 | |
| WABCO | 4324100202, 4324202202, 4324102442, 4324102227 | |
| TORQUE | TR950011, Q ABP N10GR950011 |
| Manufacturer | Bendix |
|---|---|
| Shipping Length (in) | 9.00 |
| Shipping Width (in) | 9.00 |
| Shipping Height (in) | 9.00 |
| Returnable | Yes |
| Weight (lb) | 4.00 |
| Core Exchange | No |
