Bendix BP-R1 Pressure Proportioning Valve | 65146N

Description

The Bendix BP-R1 Pressure Proportioning Valve part number BW 65146N plays a vital role in maintaining the safety and performance of air brake systems in heavy-duty vehicles. This valve, constructed with a robust exhaust port featuring a dust shield, ensures durability by safeguarding against contaminants. Its precisely set crack pressure of 5.50 psi guarantees that it activates at the appropriate pressure threshold, enabling balanced brake fluid distribution between the front and rear brakes, thus promoting safe and reliable braking. With dual supply ports and multiple delivery ports designed to accommodate various brake lines, this valve provides flexibility in brake system configurations. Its operational temperature range of -40° F to 200° F allows it to function effectively under diverse environmental conditions, making it a crucial component for the safe operation of heavy-duty trucks and vehicles.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Exhaust Port Type: Dust Shield
• Crack Pressure: 5.50 psi
• Number Of Supply Port: 2
• Length: 113.79 mm
• Width: 101.09 mm
• Height: 137.41 mm
• Mounting Dimension: 0.40 X 0.96 in
• Control Port Thread Size: 1/8-27 NPT in
• Service Port Thread Size: 1/4-18 NPT in
• Supply Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 1 Thread Size: 1/2-14 NPT in
• Delivery Port 2 Thread Size: 1/2-14 NPT in
• Delivery Port 3 Thread Size: 3/8-18 NPT in
• Delivery Port 4 Thread Size: 3/8-18 NPT in
• Supply Port 2 Thread Size: 1/2-14 NPT in
• Weight: 1.50 kg
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 200 Deg. F
