Bendix Air Drier With Drain Valves, 9, Inlet/Outlet, 0.5 Inch, National Pipe Thread Fitting | 065225
Have a Question for Our Team?
Description
The BW 065225 Bendix Air Dryer with Drain Valves is a vital component designed to maintain optimal air quality within your vehicle's braking system. Featuring a length of 223 mm and a width of 7.12 mm, this air dryer is equipped with nine inlet/outlet ports, each sporting a 0.5-inch National Pipe Thread fitting, ensuring efficient airflow management. Its primary function is the removal of moisture and contaminants from compressed air before it enters the braking system, thereby enhancing its longevity and performance. The inclusion of drain valves facilitates effective moisture elimination, while a 12 V heater, rated at 75 W, prevents freezing during colder climates. With a safety valve opening pressure of 200 psi and a robust construction, including a standard cartridge type and hard seat purge valve, this air dryer is well-suited to diverse operating conditions, with a minimum operating temperature of -40 Deg. F, making it an essential component for brake system maintenance and safety.
WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov
Features
- Length: 223 mm
- Width: 7.12 mm
- Inlet Port Thread Size: 1/2 NPT in
- Outlet Port Thread Size: 1/2 NPT in
- Supply Port Thread Size: 1/2-14 NPT in
- Control Port Thread Size: 1/4-18 NPT in
- Air Inlet Port Thread Size: 1/2 NPTF in
- Cartridge Thread Size: 5/8-11 UNC 2A in
- Mounting Thread Size: 3/8-24 UNF 2A in
- Air Delivery Port Thread Size: 1/2 NPTF in
- Delivery Port 1 Thread Size: 1/2-14 NPT in
- Cartridge Type: Standard
- Governor Included: No
- Purge Valve Type: Hard Seat
- Safety Valve Opening Pressure: 200 psi
- Heater Voltage Rating: 12 V
- Heater Wattage: 75 W
- Minimum Operating Temperature: -40 Deg. F
| OTHER | 065041, 065041X, 065111, 065133, 065141, 065152XX, 065225BXW, 065225N, 065225P, 065225PG, 065226, 065226BXR, 065226BXW, 103388, 103389, 103960, 104249, 104250, 104257, 104320, 104326, 104377, 104420, 104438, 104443, 104550, 104734, 106254, 106365, 106386, 106445, 106446, 106447, 106449, 106455, 106470, 106483, 106484, 106485, 106691, 106692, 106694, 106695, 106696, 106697, 106699, 106700, 106701, 106702, 106703, 106704, 106705, 106706, 106707, 106708, 106709, 106712, 106713, 106714, 106715, 106716, 106736, 106737, 106739, 106743, 106744, 106750, 106760, 106775, 106779, 106829, 106919, 106949, 106986, 107725, 107874, 107876, 107949, 107953, 107955, 107959, 107961, 107963, 108024, 108069, 108167, 108196, 108243, 108245, 108287, 108304, 108314, 108364, 108433, 108469, 108502, 108635, 108929, 109092, 109100, 109192, 109223, 1093793, 1093794, 109396, 109685, 109685B1, 109685BXR, 109685P, 109685PG, 109685PGX, 109685X, 109685X-BW, 109685XBW, 109689, 109727, 109728, 109729, 110112R, 1310721, 1539089, 15518195, 15535322, 15543837, 15613646, 1608371, 1620405C91, 1620677C91, 1621397C91, 1621964C91, 1673737C91, 1673827C91, 1676683C91, 170.065225, 170065225, 2072029, 23880305, 26QE357, 26QE357P2, 26QE357P3, 26QE357P4, 26QE357P5, 26QE377, 26QE377P5, 2FS82, 3500516, 448301090A, 5000765, 5003897, 5006791, 5009378, 5013547, 5017281, 5152XX, 61170150, 65041, 65111, 65133, 65141, 65152, 65224, 65225, 65225P, 65226, 65478, 65650, 6814310115, 6814310315, 6814310615, 713010016, 713010061, 745-065225, 745-109685X, 745-X109685, 745109685X, 745X109685, 801845, 90009361, 917352, AV065225, AV109685, AV65225, BAN065225, BBH-065041, BBH-065225, BBH-109685, BBH-109685R, BBH065041, BBH065225, BBH109685, BBH109685R, BHS-13728, BHS-F345, BND065225, BW065225, BW109685X, BWAD9, BWR109685, BX065041X, BX065225, BX109685, BX109685B1, BX109685X, BXK065133, DA33100, E-BN065225X, E-BN109685HX, E-BN109685X, E4HS2A131BA, E4HS2A131CA, EBN065225X, EBN109685HX, EBN109685X, F6HT2B912BB, FLTAD5225, FLTAD9685, H109685X, K065225, K065225RO, K109685, K109685RO, LAD-5586, M-65225, M65225, MERS4008507010, OTR-OTR065225, OTR065225, OTR109685, P0065225, PBC-AV065225, R109685, R955065225, R955065225X, R955109685HX, R955109685X, R955109685XCF, R955109689X, R955205, S-F345, S4008507010, SF345, V1113547, WAP22-007, WAP22007 |
|---|
| Manufacturer | Bendix |
|---|---|
| Shipping Length (in) | 18.00 |
| Shipping Width (in) | 18.00 |
| Shipping Height (in) | 12.00 |
| Returnable | Yes |
| Weight (lb) | 29.00 |
| Core Exchange | No |
