Bendix Air Disc Spring Brake Chamber | K132352

Description

The BW K132352 Bendix Air Disc Spring Brake Chamber is a part of the braking system for commercial vehicles. It has dimensions of 400 mm in length, 200 mm in width and 200 mm in height. This spring brake chamber plays a role in controlling the vehicle's brakes effectively. It has a stroke length of 2.25 inches and a push rod length of 0.59 inches, ensuring brake operation. The chamber comes with an M16 X 1.50 mm stud thread size and a port angle of 270 degrees, which allows for installation and optimal air flow. Its mounting stud center-to-center length is 4.75 inches with a mounting stud length of 1.72 inches designed for attachment with reliability in mind. Operating efficiently within temperatures ranging from -40° F to 176° F, this spring brake chamber is suitable for environmental conditions. By incorporating the Bendix Air Disc Spring Brake Chamber into your vehicle's braking system, road safety can be significantly enhanced.

WARNING: Cancer and Reproductive Harm - https://www.P65Warnings.ca.gov

Features

• Length: 400 mm
• Width: 200 mm
• Height: 200 mm
• Stroke Length: 2.25 in
• Push Rod Length: 0.59 in
• Stud Thread Size: M16 X 1.50 mm
• Port Angle: 270 deg
• Mounting Stud Center to Center Length: 4.75 in
• Mounting Stud Length: 1.72 in
• Parking Port Thread Size: 3/8-18 NPTF in
• Clamp Angle: 90 deg
• Service Port 11 Thread Size: 3/8-18 NPTF in
• Chamber Type: T18/24
• Minimum Operating Temperature: -40 Deg. F
• Maximum Operating Temperature: 176 Deg. F
